VT Series R290 Variable Speed Compressor

The VT Series R290 Variable Speed Compressor features a compact design, stable and reliable operation, and excellent cooling efficiency. It is suitable for a range of refrigeration applications, including supermarkets, convenience stores, commercial kitchens, and the medical cold chain, meeting the diverse needs of commercial customers.

Product Advantages

The VT Series R290 Variable Speed Compressor incorporates technologies such as ultra-high efficiency and low noise, enhances motor start-up performance, and optimises variable frequency logic control algorithms. Combining the high compatibility and reliability typical of commercial products, it also offers advantages such as a compact footprint, light weight, a wide COP range, and broad adaptability.

Compressor Model	Displ.	Cooling Type	Application	Motor Type	Rotation speed	Capacity				COP			Material ofwinding
	(cm³)				(rpm)	ASHRAE			CECOMAF	ASHRAE		CECOMAF
	(cm³)				(rpm)	W	BTU/h	Kcal	W	W/W	BTU/Wh	W/W
VTH3118U	4.2	F	LMBP	PMSM	1600	106	362	91	80	1.68	5.73	1.31	Al
					2400	165	563	142	124	1.73	5.90	1.35
					3000	203	693	175	152	1.75	5.97	1.37
					4500	302	1030	260	227	1.65	5.63	1.29
VTB3124U	5.5	F	LMBP	PMSM	1600	145	495	125	109	1.78	6.07	1.39	Al
					2400	225	768	193	169	1.85	6.31	1.44
					3000	282	962	242	212	1.83	6.24	1.43
					4500	412	1406	354	309	1.75	5.97	1.37
VTB3132U	7.2	F	LMBP	PMSM	1600	204	696	175	153	1.78	6.07	1.39	Al
					2400	306	1044	263	230	1.85	6.31	1.44
					3000	387	1320	333	290	1.83	6.24	1.43
					4500	566	1931	487	425	1.75	5.97	1.37

Notes:

(1) All data is subject to change without notice.

(2) *: Currently in development.

Test conditions(℃):	ASHRAE LBP	ASHRAE MBP	ASHRAE HBP
Evaporaring temp.	-23.3	-6.7	7.2
Condensing temp.	54.4	54.4	54.4
Subcooling temp.	32.2	46.1	46.1
Suction temp.	32.2	35	35
Ambient temp.	32.2	35	35
